Preplanning and detail engineering are project phases, which belong together. But they are traditionally processed using different systems. Now Eplan is integrating them. Preplanning is anchored into the system with the new Eplan Platform 2.3. Innovative functions increase project quality and data consistency, and at the same time reduce configuration costs.

Eplan 2.3 Conveyor system zoom.jpg: Integrated engineering from preplanning to basic engineering - from systems overview down to electric schematic

Preplanning is a decisive phase in the engineering process. It involves developing concepts for technical machinery/plant design and estimating initial volumes of project data. The new Eplan Platform 2.3 breaks new ground in this "key phase" for innovative designs. Whether it is graphical overviews, placeholders for functions, initial project data for drives, sensors and PLC inputs/outputs, or parts lists for calculations - comprehensive preplanning tasks can be processed directly in the Eplan Platform. The subsequent enclosure production and detailed design of the system is based on this comprehensive data - without new data entry or transfer from other systems. Users can benefit from very easy entry into this new planning method based on the Eplan Platform. This additional integration allows you to increase data consistency and project quality. At the same time, it reduces the cost of the project development process.

An overview of structures and data

The central dialogue in the Eplan Platform is the new preplanning navigator. In this dialogue, the defined segments for preplanning are displayed and administered within the project. The use of preplanning macros, and copying and moving existing segments by drag and drop makes it quick and easy to create and edit machine/ plant structures. Alternatively, the CAE software has the option of working directly in the graphical editor for preplanning. The data defined at the preplanning stage can be output in report form and used, for example, for parts lists or for calculating prices and labour. The process is integrative. Based on the preplanning in the navigator, the next phase of configuration involves deriving and producing the detailed plan, i.e. the schematic, using drag & drop. As a further alternative for data entry, the preplanning option incorporates a comprehensive import functionality allowing data to be exported into Eplan from Excel spreadsheets. This means that information from other planning departments can be taken into consideration. Using the import function preplanning structures can also be generated automatically.

Background

The engineering process for a machine/plant involves individual phases in which the initial rough drafts and ideas for the design are gradually refined and made more specific until all the documents and information required for production and construction of the machine are in place. Preplanning and basic engineering are very early project phases in which concepts for technical machinery/plant design are developed and initial volumes of project data estimated. The aim is to determine the most technically apt design and define the guidelines for subsequent detailed planning (detail engineering). To date, the tasks of preplanning have often been processed in separate systems such as graphic tools, text processing systems for specifications or tables and databases, with only very basic or no interfaces to the configuration tool. This lack of data consistency and, often, a lack of support from engineering functionalities in these systems added up to considerably more work and poor quality at the configuration phase.

Eplan 2.3 Preplanning P&ID.jpg: Plant overview (P&ID) and plant structure (navigator) for transparent and integrated preplanning.
