In comparison to the previous tools, the user has up to 20 per cent more power available to them with the new, compact, professional tools.



SUHNER, the abrasion expert, is now launching a range of completely re-engineered power tools within the scope of its C Series. One of the outstanding features of these tools is the high power output that they achieve despite being small in size. In comparison to the previous tools, the user has up to 20 per cent more power available to them with the new, compact, professional tools.



A newly designed universal motor with a 600, 500 and 270 W power input was crucial in enabling this. The company has used its many years of in-house motor manufacturing experience to create this powerhouse.



These powerful tools were designed for daily use, and SUHNER has ensured that their construction is robust and that they are ergonomic. Just as any good professional tool should, they can also cope with tough operating conditions. An LED light on the motor housing indicates when the brushes need to be changed.



This ensures that the armature is protected and that the motor has a long service life, even when used professionally for long periods of time. The exhaust air from the effective motor cooling is directed out of the front of the machine at an angle. All the new devices enable the user to execute quick tool changes.



The UBC 9-R is a hand-held compact belt grinder for detailed deburring, grinding and finishing work. The adjustable band tension and continuously adjustable belt speed which extends from 3000 to 8200 rpm, from 4.8 to 13.2 m/s, make it the ideal tool for metalwork and rail construction. Six quick change contact arms mean that the tool can be used anywhere. Abrasive belts are available in belt widths of 3, 6, 12, 16 and 19 mm.



The UTC 9-R is a compact tube polisher which is ideal for grinding and satin finishing tubes in rail construction and also ensures that even tricky spots obtain a perfect final finish. With a wraparound angle of up to 180°, it can be used to work on tubes as small as 45 mm in diameter. The band width is 30 mm. The user can change speeds continuously in a range from 3000 to 8200 rpm, from 4.6 to 12.5 m/s. A smooth start without jolting and a constant working speed provide the best conditions for producing the excellent results that are needed in rail construction.



UMC 6.R is perfect for every corner. The UMC 6.R is a hand-held electric power file which can be used for grinding and satin finishing for profiles, housing parts and rectangular pipes in metalwork and railing construction. The stroke frequency can be adjusted continuously in a range extending between 2300 and 5200 strokes/rpm. Undervoltage protection prevents the machine from starting up by accident after a power interruption. Its sleek form enables the user to access acute angles. Its power input is 500 W.



The UMB 4-RQ cross stroke file can be used for the same applications as the electric power file. It is the perfect device for enabling fast and clean work on the areas between the rods in rail construction. The stroke frequency can be adjusted continuously in a range extending between 1500 and 3750 strokes/rpm. The file also has undervoltage protection which prevents it from being switched on accidentally after a power interruption. Its power input is 270 W.



The USC 25-R and USC 9-R electric straight grinders can be used in almost all applications. They are as perfect for assembly areas as they are for construction sites, workshops and in production. The USC 25-R straight grinder is primarily intended for use with carbide cutters and formed abrasives. The speeds can be adjusted continuously between 11000 and 25000 rpm. Its sleek design enables you to work on spots that are usually tough to access. For the USC 9-R, the speeds can be adjusted continuously between 4000 and 9000 rpm.



The USC 9 R is not only electronically down-rated but also has reduction gearing. This means that the USC always gives a consistent performance, even at low speeds, and thus enables you to produce a perfect grinding finish. The USC 9-R is best suited to applications involving nonwoven brushes, combined nonwoven brushes, flap wheels and wire brushes.Both machines (USC 25-R and USC 9-R) have an electronic speed regulator to ensure constant speeds, smooth starting and the innovative warning function when the carbon brushes become worn.
