IEC 61850 SCL Manager

Kalkitech IEC 61850 SCL Manager is a comprehensive graphical tool that allows users to create, configure, view and edit all the substation elements and its data models as specified in Substation Configuration Language specification of IEC 61850. SCL Manager enable users to configure Substation and all its elements, including inter-IED Communication mapping via GOOSE, and helps to make the substation IEC 61850 compliant.

The latest edition of SCL Manager not only supports configurations of Substations, but also Hydro Power Plant, Distributed Energy Resources and Wind Power Plant. SCL Manager reduces the complexity of the IEC 61850 configuration and provides user friendly graphical interface for configuration and substation architecture definition. It allows users to build different substation architectures, and create complete system specifications. SCL Manager also allows user to link different IEDs and its data elements to the substation specification and create complete substation configuration as specified in IEC 61850. Option is provided for creation of complete IED capabilities including its functions and data elements for any new IEDs.

SCL Manager helps in defining communication schemes and mapping data as required for management of IEC 61850 elements. It also facilitates enhanced management of SCL files and its validation. The revised logical node template allows user to create complete functionalities of IEC 61850 based IEDs with minimal knowledge of IEC 61850 standard and handles all the forms of the SCL File constructs – ICD, SSD, SCD, CID, and the Edition 2 additions IID and SED.
