Spindles

• No. Of spindles: 2
• Spindle speed: 4500 rpm
• Spindle motor power (15 min/cont.): 7.5/5.5 kW
• Spindle nose: A2-5
• Distance between two spindles: 420 mm

• X-Axis: 130mm
• Z-Axis: 145mm
• Rapid traverse (X&Z): 24 m/min

• Chuck size: 170mm (diameter)
• Work piece dimension (loader capacity): 120 x 80 (diameter)

• Maximum part weight: 3 Kg
• Loader X (left/right) Axis stroke: 1850 mm
• Maximum speed (X): 120 m/min
• Loader Y (up/down) axis stroke: 560mm
• Maximum speed (Y): 90 m/min
• Loader Z (front/rear) axis stroke: 150 mm
• Maximum speed (Z): 50 m/min
• Standard loading time: 7 sec

• A perfect Line Machine with High Accuracy High Productivity
• Twin Spindle with Twin Turrets available for chucker type components
• Easy Set-up change with High Speed Machining
• Customized atomisation and conveyor table arrangements possible in option as per application requirements
• Compact Foot-print with 2 operations in one space saving set-up and change over times
• Options for Job Changeover stations available with Gantry system options
• Direct free fall of chip with efficient chip disposal and coolant system
• Thermally Stable Graded Cast Iron body with widely spaced, heavily ribbed base to damp vibration and enabling higher cutting parameters with better accuracy and dynamic performance of machine
• Higher Productivity with short positioning time with heavy duty Linear motion guide ways for greater positioning accuracy and superior surface finish.
• Linear Motion guide ways on all Axes with High Rapid Traverse Rate with better acceleration for fastest production and lowest non cutting time
• Easy to operate Swivelling Operator Panel with Hand wheel for better flexibility considering operator friendliness and TPM concept with simple job loading and unloading facilities.
• All manufactured components produced using the best machinery and equipments with stringent quality awareness at every stage.
• Various productivity enhancing feasibility options possible to interface.
• Efficient machine capability achieved with latest control systems available with options
