Lift Inverters
Lift Inverters
Soyo Systems offers Lift Inverter, Lifton Series. These inverter are totally reliable and highly durable, as we utilize optimum-grade raw material and advanced machineries to manufacture these inverters.
Product & Technology News
- Model: Three-phase output
- Rating: 6 KVA to 100 KVA
- AC input: 415 V + 15%, -20% three phase input
- Frequency: 50 Hz +/- 6%
- DC voltage: 72 V DC to 360 V DC
- Charging time: 12 hours for 90% of full capacity
- Charger type: Internal controlled rectifier type
- Inverter: IGBT, high frequency PWM
- Technology: 400 V / 415 V AC three phase, balanced
- Output voltage: +/ - 1% for DC I/P variation & O/P load variation
- Voltage regulation: 50 Hz + 0.5 Hz
- Frequency: PWM sine wave
- Waveform: Less than 3%
- Harmonic distortion: >93% for 360 V DC
- Inverter efficiency: >90% for 180 V DC
- Power factor: 0.8 105% continuously
- Overload: 300% for 60 sec
- Crest factor: 4:1
- Transient response: +/- 4% under full load change
- Phase displacement: 120 degree +/- 1%
- Audible noise: Less than 45 dB at 1 meter
- Reasonable price
- Saves power
- Long lasting
- Seamless finish
- Zero defect
