Electric Vehicle Charger

Electric Vehicle Charger

RRT Electro is engaged in manufacturing of customized Power Electronic Products over two decades having capability to Design, Develop, Prototyping, Regulatory Compliance testing & Certification, Manufacture, Supply, Install, Commission and provide Service after sales with AMC support.

  • Input: 415V AC, -10%/+15%, 50Hz + 5%, 3 Phase, 5-wire R,Y,B,N & Earth,
  • Power Factor > 0.99
  • No. of outputs :1
  • Output Voltage: 40 to 100VDC
  • Output power: 10kW
  • Output current: 135A max
  • Output Connector: GB/T 20234.3:2015 (DC fast charge)
  • Ripple: Ripple: Voltage †1%, Current<2%
  • Regulation: Voltage regulation 2%, Current regulation < †5A
  • Efficiency: >92% typical
  • Ambient: Temperature: 0 to 50°C, Humidity: 5% to 95%
  • Protection & Safety: Input—Under/Over voltage, Output– Under/Over voltage, Overload, Short circuit, Surge, Earth fault at input & output, Input power fail, Emergency shut-down with alarm, Over temperature, Electric shock
  • Cooling: Forced Air
  • Visual Indication: LED for Fault, Healthy, Charging
  • Ingress Protection: IP-54
  • Mounting: Floor Mounting
  • Dimension: 450 (W) x 250 (D) x 1650 (H) mm
  • Communication: CAN 2.0B
  • OCPP
